What Are the Best Injection Molding Materials?

Choosing the right injection molding materials begins with the product, not the resin chart. A food container, automotive clip, and medical housing face different demands. Each may need different strength, heat resistance, chemical stability, or appearance. The details matter.

PlasticsEurope reported 400.3 million tonnes of global plastics production in 2022. Its Plastics—The Fast Facts 2023 report also shows the scale of plastics use across packaging, construction, automotive, and other sectors. Grand View Research identifies expanding demand for injection molded plastics through 2030, driven by lightweight components and efficient mass production. These figures explain the opportunity, but they do not make material selection simple. A high-volume part can still fail because of warpage, weld lines, moisture, or poor dimensional control. That assumption can fail.

Engineers commonly compare polypropylene, ABS, polycarbonate, nylon, POM, and reinforced grades. They examine datasheets, processing temperatures, shrinkage values, impact results, and long-term exposure conditions. ASTM testing methods can support fair comparisons, while supplier certificates help verify grade consistency. Recycled content also deserves attention, although its performance may vary between batches. A lower-cost resin is not always the lower-cost choice. Tooling temperature, drying practice, gate design, and cycle time can change the final result. This guide evaluates the leading injection molding materials through practical performance, application fit, manufacturability, and cost. It also questions convenient recommendations, because real production conditions rarely match ideal laboratory data.

What Are the Best Injection Molding Materials?
Table of Contents [Hide]
1 Define Selection Criteria: Strength, Heat Resistance, Cost, and Cycle Time
2 Compare Commodity Resins: PP, ABS, and PE with 0.4–3.5% Shrinkage
3 Assess Engineering Plastics: PA, PC, and POM for 80–150°C Service
4 Choose High-Performance Resins: PEEK and PPS Above 200°C
5 Verify Reinforcement Choices: 10–40% Glass Fiber and Recycled Content

Define Selection Criteria: Strength, Heat Resistance, Cost, and Cycle Time

What Are the Best Injection Molding Materials?

Define Selection Criteria: Strength, Heat Resistance, Cost, and Cycle Time

Material choice in injection molding starts with the part’s job, not a favorite resin. Measure load, temperature, budget, and production volume before comparing datasheets. Strength matters when clips flex, housings face impact, or threaded bosses receive repeated assembly forces. A glass-filled resin can improve stiffness, but it may increase tool wear and create visible fiber patterns. Small mistakes matter.

Heat resistance requires more than checking a material’s maximum temperature. Consider continuous exposure, short heat spikes, chemical contact, and pressure. A housing near a motor may need dimensional stability, not just a high heat rating. Test molded samples under realistic conditions. Laboratory values can change after molding, especially with different wall thicknesses and cooling rates.

Cost includes more than resin price. Add drying requirements, scrap, cycle time, mold maintenance, and secondary operations. A low-cost material may cool slowly or need careful moisture control. That can reduce output and erase the initial saving. Cooling often controls the cycle, particularly in thick sections. Thin-wall designs may favor faster-flowing materials, but filling problems can increase waste. In practical mold reviews, a short trial run reveals details that spreadsheets miss. I have seen teams select a technically strong resin, then regret its slow processing. The better decision balances performance with repeatable production, while accepting that early assumptions may need revision.

What Are the Best Injection Molding Materials?

Material selection depends on the balance between tensile strength, heat resistance, material cost, and molding cycle time. The chart uses a 0–100 performance index: higher values are better, including lower cost and shorter cycle time.

Representative engineering values: tensile strength and heat resistance are based on common unfilled grades; cost reflects typical resin price ranges of approximately $1.2–$30 per kg; cycle time reflects typical molded-part production conditions. Actual results vary with part thickness, mold design, drying requirements, and processing parameters.

Compare Commodity Resins: PP, ABS, and PE with 0.4–3.5% Shrinkage

What Are the Best Injection Molding Materials?

For common molded parts, shrinkage often decides the material choice. Published engineering datasets and ISO 294-4 testing references report different ranges by grade and processing condition. Polypropylene, or PP, commonly shrinks about 1.0–2.5%. Its flow, chemical resistance, and low density suit housings, caps, and living hinges. ABS usually shows lower shrinkage, around 0.4–0.8%. It offers good dimensional stability, impact strength, and surface appearance. Polyethylene, or PE, can shrink approximately 1.5–3.5%, especially in high-density grades. Its toughness and moisture resistance help with containers and flexible components.

These figures are not guarantees. Mold temperature, packing pressure, wall thickness, gate position, and cooling time can shift actual results. Industry processing guides and ISO 294-4 measurement practices emphasize testing under controlled conditions. A thin PP wall may behave differently from a thick ribbed part. That detail is easy to miss. I have seen designs fail because engineers used one shrinkage value for every cavity. The shortcut looked efficient, but it created uneven dimensions and visible sink marks.

Tips: Build a material-specific shrinkage allowance into the mold design. Validate it with trial parts, not only datasheet numbers. Use PP when flexibility matters, ABS when tighter dimensions matter, and PE when toughness or chemical resistance dominates. Recheck the decision after adding colorants, fillers, or recycled content. Those changes can alter flow and shrinkage.

Assess Engineering Plastics: PA, PC, and POM for 80–150°C Service

What Are the Best Injection Molding Materials?

Assess Engineering Plastics: PA, PC, and POM for 80–150°C Service

Choosing an injection molding material for 80–150°C service requires more than checking a datasheet. Actual performance depends on load, exposure time, humidity, wall thickness, and cooling design. A molded housing may survive a short heat cycle, yet deform under constant stress. Testing matters.

Polyamide (PA) offers strong mechanical performance and good wear resistance. However, it absorbs moisture, which can change dimensions and reduce stiffness. Drying before molding is essential. Conditioning after molding should also be included in validation. For reinforced PA, fiber orientation may create uneven shrinkage. That detail is easy to overlook.

Polycarbonate (PC) provides excellent impact resistance and stable dimensions across many applications. Continuous exposure near 130°C needs careful grade selection and heat-aging tests. Moisture control remains important during processing. Stress cracking can occur around sharp corners or molded-in stress. POM is a strong option for low-friction parts, gears, guides, and sliding components. It machines and molds accurately, but prolonged high-temperature exposure can reduce strength and accelerate oxidation. Proper stabilization and ventilation are necessary during molding.

No material wins every case. A better review combines tensile testing, creep testing, humidity conditioning, and repeated thermal cycling. I would also inspect real parts, not only test bars. That is where small design weaknesses often appear. Cost can influence the decision, but replacing a distorted part is usually more expensive.

What Are the Best Injection Molding Materials? — Assess Engineering Plastics: PA, PC, and POM for 80–150°C Service
Assessment Dimension PA
(Unfilled PA6/PA66)		 PC
(Unfilled Polycarbonate)		 POM
(Unfilled Acetal)		 Design Interpretation
Typical continuous-use temperature in air Approximately 80–120°C, depending strongly on moisture conditioning and load Approximately 100–130°C; short-term exposure can be higher with limited mechanical load Approximately 90–110°C; prolonged exposure near the upper limit requires validation For sustained service near 150°C, standard unfilled grades of all three materials generally require a higher-temperature alternative, reinforcement, or a reduced mechanical load.
Melting or glass-transition behavior PA6 melting point about 220°C; PA66 about 255–265°C; glass transition typically about 45–80°C depending on moisture Glass transition typically about 145–150°C; amorphous material with no sharp melting point Melting point typically about 165–180°C; crystalline material A material can remain solid above its glass-transition temperature, but stiffness and creep resistance may decline significantly.
Density Approximately 1.12–1.15 g/cm³ Approximately 1.18–1.22 g/cm³ Approximately 1.39–1.43 g/cm³ POM is typically the densest of the three; density has a direct effect on part weight and material usage.
Tensile strength at room temperature Approximately 45–85 MPa, depending on polymer type, moisture state, and processing Approximately 55–75 MPa Approximately 55–75 MPa Published values are commonly measured on molded specimens and should not be treated as allowable design stress.
Tensile modulus at room temperature Approximately 1.5–3.0 GPa; moisture generally lowers stiffness Approximately 2.1–2.5 GPa Approximately 2.5–3.5 GPa POM commonly provides the highest stiffness among these unfilled materials, while dry PA can also be relatively stiff.
Impact resistance Good to very good; toughness generally increases after moisture absorption Very good; strong resistance to sudden impact and notch sensitivity Good for many applications, but generally less impact-tolerant than PC PC is usually the safest choice where high impact resistance is the primary requirement.
Moisture absorption at equilibrium Relatively high: commonly about 1.5–3.0% by weight, depending on PA type and humidity Low to moderate: commonly about 0.1–0.3% by weight Low: commonly about 0.2–0.3% by weight PA dimensions, strength, stiffness, and molding shrinkage can change materially with humidity and conditioning history.
Dimensional stability Fair to moderate; moisture-related dimensional change must be considered Good; relatively low moisture sensitivity, but thermal expansion can be significant Good to very good; low moisture sensitivity, with crystallization-related shrinkage requiring control POM and PC are generally easier to control dimensionally in humid environments than unfilled PA.
Creep resistance at 80–100°C Moderate; improves when reinforced, but depends strongly on moisture condition Moderate; design stress should be reduced as temperature approaches the glass-transition region Good for short- and medium-term loads; long-term stress still requires creep data Use temperature-specific creep curves rather than room-temperature tensile values for load-bearing parts.
Friction and wear performance Good in many sliding applications; grade and counterface strongly affect results Usually not the first choice for dry sliding or abrasive contact Very good for low-friction, low-wear gears, bushings, and sliding components POM is commonly preferred for precision moving parts, provided temperature, lubrication, and contact pressure are controlled.
Chemical resistance Good against oils and many hydrocarbons; acids and some solvents can be problematic Good against dilute acids and many oils; vulnerable to alkalis, some solvents, and stress cracking Good against fuels, oils, and many solvents; strong acids and oxidizers can attack it Always screen the exact chemical, concentration, temperature, exposure time, and molded-in stress combination.
Hydrolysis and hot-water sensitivity Generally better than PC in hot-water service, but long-term high-temperature humidity can reduce properties Sensitive to prolonged hot-water exposure and hydrolysis at elevated temperature Usually good in water, but hot oxidizing environments and strong acids require caution For hot-water or steam applications, validate mass change, tensile retention, dimensional stability, and creep.
Injection-molding considerations Requires thorough drying; processing window varies by PA type and moisture level Requires careful drying; high melt temperature and mold temperature help surface quality and reduce residual stress Requires controlled melt and mold temperatures; excessive residence time can cause degradation Part thickness, gate design, mold temperature, cooling uniformity, and annealing can affect final performance.
Suitability for 80–100°C service Good with moisture control Good Very good All three can be viable when stress, environment, tolerance, and lifetime requirements are appropriately defined.
Suitability for 100–130°C service Conditional Good to conditional Conditional PC often offers the best toughness, while POM may offer better sliding performance; PA requires especially careful humidity and creep evaluation.
Suitability for 130–150°C service Limited for standard grades Limited under sustained load Generally limited Consider heat-stabilized or reinforced grades, higher-temperature engineering polymers, reduced stress, thermal cycling tests, and long-term aging data.
Best-fit application profile Structural parts requiring toughness, fatigue resistance, and a balance of strength and cost; moisture must be included in the design basis. Transparent or opaque housings, guards, electrical parts, and components requiring high impact resistance and dimensional consistency. Gears, rollers, bushings, clips, pumps, and precision mechanisms requiring low friction, wear resistance, and stable dimensions. Material selection should be based on the complete load–temperature–environment combination rather than temperature alone.
Note: Values are representative ranges for unfilled injection-molding grades and are intended for preliminary material screening. Actual properties vary with polymer type, moisture condition, molding parameters, specimen geometry, orientation, additives, and test method. Final designs should be verified using supplier-neutral material data, temperature-specific creep testing, chemical compatibility testing, and accelerated aging.

Choose High-Performance Resins: PEEK and PPS Above 200°C

What Are the Best Injection Molding Materials?

Choose High-Performance Resins: PEEK and PPS Above 200°C

When service temperatures exceed 200°C, ordinary engineering plastics can soften, creep, or lose strength. PEEK and PPS become practical choices for demanding injection molded parts. PEEK offers excellent fatigue resistance, chemical stability, and reliable performance near 250°C in suitable grades. Its melting point is about 343°C, so processing demands are substantial. PPS typically withstands continuous heat around 200–220°C, depending on grade and load. It also resists chemicals and absorbs very little moisture.

Processing discipline matters as much as resin selection. PEEK usually needs thorough drying, controlled melt temperatures, and a hot mold. PPS also requires careful drying and stable temperature control. Mold temperatures often exceed 120°C, while melt temperatures may approach 350°C. Tooling must tolerate repeated thermal cycling. Poor venting can leave burn marks, trapped gas, or incomplete filling.

Small details matter.

Glass or carbon reinforcement can improve stiffness and reduce thermal expansion, but it may increase tool wear. Fillers can also make weld lines more visible. Designers should check wall thickness, gate location, shrinkage data, and post-molding stresses before production. In practical trials, a material that looks perfect on a data sheet may warp unexpectedly. That lesson is easy to overlook. Test coupons, actual geometry, and long-duration heat exposure provide more reliable evidence than short laboratory comparisons.

Verify Reinforcement Choices: 10–40% Glass Fiber and Recycled Content

Choosing an injection molding material starts with the load, temperature, and surface requirement. Glass fiber can raise stiffness, but its percentage changes processing behavior. At 10%, a housing may gain useful rigidity without severe loss of toughness. At 20–30%, warpage, weld-line weakness, and fiber orientation deserve closer attention. At 40%, the part can become very stiff and more abrasive to tooling. More reinforcement is not automatically better. Actual results depend on resin type, fiber length, gate design, and cooling balance.

In production trials, I check molded plaques and the finished part, not only the supplier data sheet. Measure shrinkage along and across flow. Inspect the gate, ribs, corners, and screw bosses for sink marks or cracks. Recycled content adds another variable. Verify its percentage, source, moisture level, melt-flow range, and previous thermal history. A recycled stream can perform well, yet its properties may shift between lots. That assumption was too simple in one early trial. Stable inspection records matter.

Blend decisions should use test data from the intended machine and mold. Compare tensile strength, impact resistance, heat deflection, dimensional change, and appearance. Run samples after normal drying and realistic cycle times. Shorter fibers may reduce stiffness while improving flow, but the trade-off needs measurement. Keep a retained sample from each material lot. Small changes in recycled content can alter color, odor, or surface texture. Do not approve 40% glass fiber or recycled content by percentage alone. Approve the measured performance.
