Magnetic Therapy Device Moulding

We have design and production capabilities related to magnetic therapy devices, such as: CAD design, mold manufacturing, injection molding, plastic product production, assembly and other technologies. In addition, our company has established cooperative relationships with plastic raw material suppliers, printing manufacturers, etc. to ensure the supply of raw materials and printing quality. Through our rich experience and perfect supply chain, our company can provide customers with high-quality customized magnetic therapy device products to meet their specific needs. At the same time, we have 10 years of professional foreign trade service experience, understand the foreign trade process, and better serve customers. For magnetic therapy device products, we can make corresponding plastic parts or corresponding metal parts. We can produce plastic parts. This is mainly done through injection molds, and we can make metal parts, which can be made by injection molding or die casting.

In terms of materials, because the main materials of magnetic therapy products are relatively special, PA12 (temperature resistance 150℃)/PPS (temperature resistance 180℃) mixed with 30% NdFeB magnetic powder is generally used. We can make the shell of the magnetic therapy device according to the materials the customer wants. In short, as long as you want the material, we can provide it. We have a variety of raw material suppliers, and raw materials of any brand and model can be provided. As long as the customer provides the purpose of the product, we can choose the most suitable material according to the purpose of the product. Even modified plastic materials/special plastic materials, we can provide them. For example, the screen of some magnetic therapy products can adjust the mode by touch. This screen requires conductive PMMA material, which is a special modified material we can provide.

In the design of magnetic therapy products, we have sufficient surface design experience and professional designers. We understand the design structure of magnetic therapy products and know what kind of surface design/structural design can make users use magnetic therapy products more comfortable and convenient.

In the design of magnetic therapy molds:

1. Embedded magnet positioning: Use slider + inclined top device to ensure the positioning accuracy of magnet inserts ±0.05mm to prevent reverse magnetic poles

2. Integrated magnetization design: 8000-9000 Gauss strong magnets are integrated in the mold, and radially symmetrical magnetic field distribution is achieved through magnetic tungsten steel sleeves to reduce the post-magnetization process

3. Molding system: split mold core design, inserts use magnetic steel sheets.

Function: avoid magnetic line interference, magnetic pole direction error ≤2°

4. Cooling system: conformal water channel + mold temperature controller control, mold temperature is stable at 60±2℃

Function: magnetic powder filling rate is increased by 15%, and shrinkage is controlled within 0.08mm

5. Exhaust system: 0.03mm stepped exhaust groove + vacuum assistance

Function: Eliminate the air marks around the magnet, and the yield rate is increased to 98%

In terms of molds, the magnetic therapy device is mainly made of corresponding plastic shells. The plastic shell part can choose 45#, p20, 718, 718H, S316, H13 to make molds. The choice depends on the customer's requirements for product life. We are experienced in this area. For the lenses, the mold material must be at least S136 grade to be perfectly made. We have made hundreds of lenses with different requirements to meet customer requirements. If there are special mold requirements, we can also do it. We generally use the cold runner system because it is cheaper. If the customer wants a hot runner system, we can also do it, but the cost of hot runner and cold runner is completely different. We will do it according to the customer's requirements.

Solutions to typical problems of magnetic therapy device injection molding

1. Magnetic powder segregation: use a two-stage screw, compression ratio 2.5:1, and reduce the temperature of the mixing section by 20°C

2. Uneven magnetization: add magnetic pole positioning pins and cooperate with a 0.02mm grade mold guide system

3. Demolding damage: use silicon nitride ceramic ejector pins in the ejection system, and reduce the friction coefficient to 0.1

Magnetic therapy device Mold

We are a Magnetic therapy device mold manufacturer, providing high-quality Magnetic therapy device mold manufacturing. As long as you want to customize/develop Magnetic therapy device products, you can find us. We have professional injection mold design and mature manufacturing technology, providing you with one-stop service, from product design-mold making-product production-product packaging-product transportation, we can help you in every link. As long as you come to us, we will provide you with the ultimate service and satisfy you in terms of product quality, production time, information dialogue, etc.

Plastic Injection Mould making

Plastic molding specifications

Mold design:

Transaction process:

Mold testing:

Product packaging

Factory

We are Custom Plastic Mold factory. Our factory is plastic injection mold maker. we has 17 years of experience in professional custom plastic mold and 10 years of foreign trade experience. We are custom Plastic Mold supplier. We can provide custom Plastic Mold service. Our factory can make the Injection molded plastic parts, and the quality of the products will satisfy you.

We have more than 50 high-end machines and hundreds of engineers and designers. We can provide one-stop service, from product design - mold making - product production - product packaging - transportation. We have a complete production chain. We can meet all your requirements.

Services we provide:

Professional custom mold service, Plastic mold design and manufacturing .plastic product production, product design, mold design, blow mold customization, rotational mold customization, die-casting mold customization. 3D printing services, CNC manufacturing services, product packaging, customized packaging, shipping services.

We always adhere to the principles of quality first and time first. While providing customers with the highest quality products, try to maximize the production efficiency and shorten production time. We are proud to tell every customer that our company has not lost any customer since its establishment.If there is a problem with the product, we will seek a solution actively and take responsibility to the end.
